Product Manufacturing & Prototyping

Delivering high‐quality custom metal fabricated solutions for our customers’ complex supply chain requirements

Typical Industries

Aerospace
Battery / Power Systems
Building / Infrastructure
Computer / Electronics
Environmental
Fire Suppression
Medical Device
Security Systems
Telecommunications
Transportation

Typical Products & Assemblies

Enclosures: Boxes, Cabinets, Chassis
Electro-Mechanical Assemblies:
-Card Guide, Fan Tray, Cable/Harness
Panels:
-Instrument, Lighting, Card Slot, Door
Plates, Handles, Frames &Brackets

Value Added Service

Design for Manufacturability
Electro-Mechanical Assembly
Compliance Certifications
Custom Part Marking & Labeling
Inventory Management
Kitting
Product Testing
Sustainable Packaging
Supply Chain Alignment

Material Types

Aluminum
Hot & Cold Roll Steel
Galvanized/Galvanealed Steel
Stainless Steel
Copper / Brass
Plated/Prepainted Material
Lexan / Inconel

Maximized Material Utilization

Increased Productivity

Decreased Turn Around Time

Programming Software

Amada Dr. Abe Blank – Amada Dr. Abe Bend – Amada MX WIN BendCam Software – Nestmaster Nesting Software – Pro-E CAD – SMP Merry Mechanization – Solidworks CAD

Photo shows: 96 pieces nested onto 48” X 96” sheet 5 extra parts in center of each main part Use of SMP NestMaster software Reduced material waste Increased productivity

Design Assist for Manufacturability

DRAW an original part in SMP/IS

IMPORT part data with CAD interface utility and SolidWorks CAD software

MAXIMIZE material utilization through NestMaster true-shape nesting software

Accurate flat patterns are developed quickly and can be checked for manufacturability, without physically producing a part.

Corrections can be made before the manufacturing process begins, producing a correct prototype the first time and saving valuable machine time and material.
